Detailed Description

The PTGPE Series High-Frequency Pure Sine Wave Inverter features an intelligent color display, advanced imported chips, and proprietary control software to deliver high-quality pure sine wave output, providing power quality superior to standard mains electricity.


With fully isolated input and output circuit design, the system ensures enhanced safety, stable performance, and reliable operation. The upgraded digital remote control and optional Bluetooth APP enable convenient monitoring and control, making it especially suitable for outdoor, RV, and mobile power applications.


Product Features

Intelligent Color Display & Remote Control Panel

Pure Sine Wave Output

Optional Bluetooth & Wireless Remote Control

Optional RS485 Communication Interface

Wide DC Input Voltage Customization

Multiple AC Socket Options

Stable Full-Load Performance


Parameters

ModelPTGPE-500
Rated power500W
Peak power1000W
Input voltage12/24/48VDC (customizable)
Output voltage110/220VAC±5%
USB port5V2A
Type-C outputOptional(PD30W/PD60W )
Frequency50Hz ± 3 or 60Hz ± 3
Output waveformPure Sine Wave
Soft startyes
Total harmonic distortion THDTHD<3% (linear load)
EfficiencyMaximum 94%
DC input range12V(10V-15.5V); 24V(20V-31V); 48V(40V-61V)
Input undervoltage alarm12V(10.5V±0.5V); 24V(21V±0.5V); 48V(42V±1V)
Input undervoltage protection12V(10V±0.5V); 24V(20V±0.5V); 48V(40V±1V)
Input undervoltage recovery12V(13V±0.5V); 24V(24V±0.5V); 48V(49V±1V)
Input Overvoltage Protection12V(16V±0.5V); 24V(31V±0.5V); 48V(51V±1V)
Input overvoltage recovery12V(14.8V±0.5V); 24V(29V±0.5V); 48V(59V±1V)
Refrigeration methodIntelligent fan
Protection functionUndervoltage protection, overvoltage protection, overload protection, over temperature protection, short circuit protection, reverse connection protection (fuse)
Working temperature-10°C ~ 50°C
Product size (cm)21*11 3*5.5
Package size (cm)65.5*43.5*31.3/16PCS
NW./PCS (kg)1.25
GW./Ctn (kg)22.5
Packaging methodCarton
Warranty2Year
