PTPM-SOC Power Manager
PTPM SOC Power Manager

PTPM-SOC Power Manager

Intelligent Overload Protection
Bluetooth Monitoring (Optional)
IP65 Waterproof Outdoor Design

+8613736779975

+8613736779975
sales@vcbbreaker.com

sales@vcbbreaker.com
http://www.prominentcn.com/

http://www.prominentcn.com/
No.66 Punan Road, Yueqing Economic Development Zone, Zhejiang, China

No.66 Punan Road, Yueqing Economic Development Zone, Zhejiang, China

Detailed Description

The PTPM SOC Power Manager is an intelligent power management device designed to control and optimize inverter output loads through multiple independent routes. Working in coordination with Bberry lithium batteries, the power manager can automatically switch ON/OFF specific AC output circuits based on the battery State of Charge (SOC).


This intelligent load management ensures efficient energy utilization, extended battery life, and reliable system operation, making it ideal for Energy Storage Systems, off-grid solar systems, backup power solutions, and smart energy management applications.

Parameters

ItemRoute1Route2Route3
AC input10kW
Max input power50/60Hz
Frequency220VAC+10%
Input voltage
AC Output10kW
Max power in total
Disconnect SOC (default value)40%20%10%
Reconnect SOC default value60%40%30%
Settable SOC range0%-99% settable
Output voltage220VAC±3%
Others
ProtectionOverload, low voltage
CommunicationCAN
Other optionalBluetooth/Wifi(TBD)
